Professional Mobile Phone Reader
Large Field of View
| Suzhou SuperMax Smart System Co., Ltd. | 7180 Technical Specification |
| Physical Characteristics | |
| Dimensions: | 135mm x 105mm x 100mm |
| Weight: | 305g |
| Voltage: | 5 VDC |
| Working Current: | 300mA |
| Standby Current: | 100mA |
| Peak Current: | 350mA |
| Performance Characteristics | |
| Image (Pixels): | 640 pixels (H)x 480 pixels (V) |
| Light Source: | Illumination:6500K LED |
| Field of View: | 40.5° (H) x 31° (V) |
| Roll / Pitch / Yaw: | 360°, ±65°, ±60° |
| Print Contrast: | 20% minimum reflective difference |
| Motion Tolerances | >2m/s |
| Interfaces Supported: | USB, RS232 |
| Symbology Decode Capability | |
| 1-D: | UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Codabar Interleaved 2 of 5, Mis Plessey, GSI DataBar, China Postal, Korean Postal, etc. |
| 2-D: | PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec Hanxin, etc. |
| Minimum Resolution | ≥3.9 mil |
| User Environment | |
| Operating Temperature: | -20°C to 50°C |
| Storage Temperature: | -30°C to 80°C |
| Humidity: | 0% to 95% relative humidity, non-condensing |
| Shock Specifications: | Designed to withstand 1.5m(5') drops |
| Ambient Light Immunity: | 0-100,000 Lux. |
| Decode Ranges | |
| 6.88 mil (PDF417) | 0mm-50mm |
| 13 mil (100%Upca) | 5mm-110mm |
| 20 mil (QR) | 0mm-100mm |
| Performance may be impacted by bar code quality and environmental conditions | |
